[物聯汪汪]附發票~ OpenSTLinux STM32MP157F-DK2開發套件取代STM32MP157C-DK2

Common featuresSTM32MP157 Arm®-based dual Cortex®-A7 800 MHz 32 bits + Cortex®-M4 32 bits MPU in TFBGA361 packageST PMIC STPMIC14-Gbit DDR3L, 16 bits, 533 MHz1-Gbps Ethernet (RGMII) compliant with IEEE-802.3abUSB OTG HSAudio codec4 user LEDs2 user and reset push-buttons, 1 wake-up button5 V / 3 A USB Type-C® power supply input (not provided)Board connectors:Ethernet RJ454 × USB Host Type-AUSB Type-C® DRPMIPI DSISMHDMI®Stereo headset jack including analog microphone inputmicroSD™ cardGPIO expansion connector (Raspberry Pi® shield capability)ARDUINO® Uno V3 expansion connectorsOn-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration capability: Virtual COM port and debug portSTM32CubeMP1 and full mainline open-source Linux® STM32 MPU OpenSTLinux Distribution (such as STM32MP1Starter) software and examplesSupport of a wide choice of Integrated Development Environments (IDEs) including IAR Embedded Workbench®, MDK-ARM, and STM32CubeIDEBoard-specific features4＂ TFT 480×800 pixels with LED backlight, MIPI DSISM interface, and capacitive touch panelWi-Fi® 802.11b/g/nBluetooth® Low Energy 4.1
